Purolite C100E Water Softener Resin

Purolite C100E |
MSRP: US$105.00 Starting at: US$83.97 Choose Option: Bulk quantity discounts available. For bulk quantities, please call 1-866-376-2690 for price quote.
Write a review. Found a Lower Price? Request a Price Beat |
high-capacity and economical cation exchange water softening resin
Purolite C100E cation water softener resin is a high-capacity and economical ion exchange water softening resin used in new water softeners and to re-bed existing water softeners.
- gel polystyrene strong acid cation exchange resin
- economical price
- high capacity of up to 33,000 grains per cubic foot
- 8% cross-linked
- Water Quality Association Gold Seal Validated to conform to NSF/ANSI Standard 61
- Made in the USA
Operating Conditions / Requirements: | |||||||
---|---|---|---|---|---|---|---|
Polymer Structure: | Polystyrene / min 8% cross-linked | ||||||
Physical Form / Appearance: | Golden yellow spherical beads | ||||||
Functional Groups: | Sulfonic Acid | ||||||
Ionic Form as Shipped: | Sodium | ||||||
Regenerant: | Sodium or Potassium chloride | ||||||
Recommended Service Flow Rate: | 5-7.5 GPM/ft3 | ||||||
Flow Direction: | Downward Flow | ||||||
Backwash Flow Rate: | 5-6 GPM/ft2 | ||||||
Typical Freeboard: | 50% | ||||||
Recommended Bed Depth: | 30-36 Inches | ||||||
Maximum Feed Temperature: | 120°C (248.0°F) | ||||||
pH Range: | 0 to 14 | ||||||
Weight: | Approx. 50 lbs per Ft3 |
Recommended Configurations for Residential and Light Commercial Applications | |||||||
---|---|---|---|---|---|---|---|
Tank Size: |
8 x 44 | 9 x 48 | 10 x 54 | 12 x 52 | 13 x 54 | 14 x 65 | 16 x 65 |
C100E Resin Volume (Cubic Feet): |
0.75 | 1.0 | 1.5 | 2.0 | 2.5 | 3.0 | 4.0 |
Maximum Capacity @ 15 lbs of salt per CF: |
24,750 | 33,000 | 49,500 | 66,000 | 74,250 | 99,000 | 132,000 |
Maximum Capacity @ 9 lbs of salt per CF: |
20,250 | 27,000 | 40,500 | 54,000 | 60,750 | 81,000 | 108,000 |
Maximum Capacity @ 6 lbs of salt per CF: |
16,500 | 22,000 | 33,000 | 44,000 | 49,500 | 66,000 | 88,000 |
Bed Depth (Inches): |
26* | 27* | 33 | 30 | 32 | 34 | 34 |
Recommended Service Flow Rate (GPM)*: |
3.5 to 7.0 | 5.0 to 10.0 | 7.0 to 14.0 | 10 to 20 | 12 to 24 | 16 to 32 | 22 to 44 |
Maximum Recommended Flow Rate (GPM)*: |
10 | 15 | 20 | 30 | 36 | 48 | 65 |
Backwash Flow Rate (GPM) at 60F: |
1.7 | 2.2 | 2.7 | 3.9 | 4.6 | 5.4 | 7.0 |
* Bed Depth not optimal due to tank height.
