Whole house water filters We are pleased to offer a wide selection of whole house water filters designed specifically to meet the higher water flow rates encountered on a home's main incoming water line. In addition to offering basic systems designed to remove sediment, dirt, and rust particles, we also offer a complete range of whole house water filter packages for the removal of chlorine, chloramine, cysts, VOC's, iron, hydrogen sulfide (rotten egg smell), certain heavy metals, and a wide range of contaminants responsible for bad taste and odors in residential water supplies. We also stock Trojan UVMax and Sterilight ultraviolet (UV) water purifiers which are designed specifically to sterilize residential water to kill bacteria and viruses.

Our whole house systems are designed for high flow rate applications, however, it is always important to note that as with all water treatment applications, the faster you flow water through the system (higher flow rate), the less effective the filter will be. To help you select a system that will provide you with the best possible contaminant removal rates, please note the maximum flow rates specified for each system and select a model that suits your maximum flow rate needs in your home.

We are pleased to offer most of our whole house systems in a High-Flow Series design for even higher flow rate capacity!

Why choose one of our whole house systems?

we use only the highest quality heavy duty filter housings with large diameter inlet and outlet for less pressure drop and better flow dynamics
all of our housings are made from materials that are NSF-approved for drinking water applications
we use standard filter sizes so you will always be able to obtain replacement filters for your system
many competitors use small 2.5" x 10" filters in their whole house filter systems, resulting in poor water pressure, short filter life, and less than optimal flow characteristics - we use filters with much greater surface area and dirt-holding capacity to maximize contaminant removal, improve water pressure and flow characteristics, and extend filter life so you have less maintenance to do!
great pricing on system packages and replacement filters - guaranteed best prices in USA and Canada on all replacement filters purchased by the case!

A whole house filter system is generally comprised of at least one filter housing, mounting bracket, at least one filter cartridge, and a spanner wrench. For all tasks other than just basic sediment removal, we generally recommend that a whole house water filtration system be comprised of two housings in series. The first usually serves as a sediment filter to rid the water of large particles and sediment (sand, dirt, debris, etc.). The second (usually an activated carbon filter) provides finer filtration and absorbs chlorine and other contaminants that effect water taste and odor. Additional elements can be added to the system to reduce/remove special contaminants such as iron, manganese and hydrogen sulfide (iron / Hydrogen sulfide reduction filter) or bacteria (Whole House Ultraviolet (UV) System). Most of our packages also come with spare filters!

Whole house filters can be installed by a homeowner who has basic household plumbing experience, or if your prefer, by any licensed plumber.


All of our whole house filter packages feature:

heavy duty "Big Blue" housing(s) with pressure
relief valve
sturdy mounting bracket
NSF certified housings
NO backwashing or media regeneration required!
do not add harmful bi-products to your
drinking water
relatively long filter life - cost effective
long-term operation
simple installation
small size - save valuable floor space!
high flow design and low pressure drop
easy to replace filters - handy spanner wrench included with all systems
Sterilight ultraviolet UV sterilizers Trojan UVMax ultraviolet (UV) purifier ultraviolet (UV) purifier

For information on our
replacement filters,
please CLICK HERE
.

Let us help select a system that suits your needs... What do you want to remove from your water?

whole house water filter ratings

Model Sediment, Dirt, Rust Particles, Turbidity Chlorine, THMs, Bad Tastes & Odors Chloramine, Bad Tastes & Odors Volatile Organic Chemicals (VOCs) Iron
&
Manganese
Hydrogen Sulfide (rotten egg smell) Hardness & Hard Water Scale Cysts (*) Bacteria / Viruses
WH1
Sediment Filter

10 microns
- - - - - - - -
WH1-HF
Sediment Filter

10 microns
- - - - - - - -
WH1B+
Sediment Filter

5 microns
- - - - - - - -
WH1B+-HF
Sediment Filter

5 microns
- - - - - - - -
WH2
Carbon Block

5 microns
- - - -
WH2-HF
Carbon Block

5 microns
- - - -
WH3
GAC

10 microns
- - - -
WH3-HF
GAC

10 microns
- - - -
WH
Chloramine

10 microns
- - - -
WHC+
0.5 microns
- - -
WH5
Iron Filter

not rated
- - - - - -
WH5+
Iron Filter

20 microns
- - - -
WH KDF
10 microns
- - - -
Trojan
UVMax
- - - - - - -
Sterilight
UV
- - - - - - -

* Cryptosporidium and Giardia

Recommended whole house water filter systems:

Whole House Water Filter Categories:
sediment water filters

Sediment
Filters
chlorine, taste and odor, carbon filters
Chlorine, Chloramine,
General Taste/Odor
Water Filters
Iron & Hydrogen Sulfide Filters
Iron &
Hydrogen Sulfide
Filters
Ultraviolet (UV) water purfiers
Ultraviolet (UV)
Water Purifiers
(Bacteria &Viruses)
FreshPoint Ultrafiltration System

FreshPoint
Ultrafiltration


Whole House Sediment Filter Packages

click on the picture for more information WH1 10 Micron Sediment Filter
WH1 10 Micron Whole House Sediment Filter Package
WH1-HF High Flow Series 10 Micron Sediment Filter
WH1-HF High Flow Series 10 Micron Whole House Sediment Filter Package
WH1B+ 5 Micron Sediment Filter
WH1B+ 5 Micron Whole House Sediment Filter Package
WH1B+-HF High Flow Series 5 Micron Sediment Filter
WH1B+-HF High Flow Series 5 Micron Whole House Sediment Filter Package
Application General sediment filtration for average to large home General sediment filtration for very large home, applications where high sediment contamination is present, and for commercial applications Fine sediment filtration or UV sterilizer pre-treatment for average to large home Fine sediment filtration or UV sterilizer pre-treatment for very large home, applications where high sediment contamination is present, and for commercial applications
Suitability municipal (city), lake, stream or well water municipal (city), lake, stream or well water municipal (city), lake, stream or well water municipal (city), lake, stream or well water
Micron Rating 10 microns nominal 10 microns nominal 5 microns nominal 5 microns nominal
Max. Recommended Flow Rate (Gallons per Minute) 10 GPM (38 LPM) 20 GPM (76 LPM) 10 GPM (38 LPM) 20 GPM (76 LPM)
Pressure Drop @ Maximum Flow Rate <2 PSI <2.5 PSI <2 PSI <2.5 PSI
Housing 10" Heavy Duty Big Blue Housing - Polypropylene - NSF Certified Standard 42 20" Heavy Duty Big Blue Housing - Polypropylene - NSF Certified Standard 42 10" Heavy Duty Big Blue Housing - Polypropylene - NSF Certified Standard 42 20" Heavy Duty Big Blue Housing - Polypropylene - NSF Certified Standard 42
Filter Liquatec SDF-45-1010 - Package includes 4 filters (3 spares)! Liquatec SDF-45-2010 - Package includes 3 filters (2 spares)! Pentek DGD-5005 - Package includes 4 filters (3 spares)! Pentek DGD-5005-20 - Package includes 3 filters (2 spares)!
Mounting Bracket Included - Stainless Steel Included - Stainless Steel Included - Stainless Steel Included - Stainless Steel
Spanner Wrench Included Included Included Included
Recommended Operating Temp. Range 40-100F (4.4 to 37C) 40-100F (4.4 to 37C) 40-100F (4.4 to 37C) 40-100F (4.4 to 37C)
Maximum Recommended Water Pressure 100 PSI (6.9 bar) 90 PSI (6.2 bar) 100 PSI (6.9 bar) 90 PSI (6.2 bar)
Package Price in USA US $139.95
BUY NOW

US $179.95
BUY NOW

US $149.95
BUY NOW

US $199.95
BUY NOW

Package Price in Canada CDN $139.95
BUY NOW

CDN $179.95
BUY NOW

CDN $149.95
BUY NOW

CDN $199.95
BUY NOW





Whole House Carbon Filter Packages

click on the picture for more information WH2 5 Micron Carbon Block Filter
WH2

Premium 5 Micron Whole House Carbon Block Filter Package
WH2-HF High Flow Series 5 Micron Carbon Block Filter
WH2-HF

Premium High Flow Series 5 Micron Whole House Carbon Block Filter Package
WH3 Granular Activated Carbon Filter
WH3

Whole House Granular Activated Carbon Filter Package
WH3-HF Granular Activated Carbon Filter
WH3-HF

High Flow Series Whole House Granular Activated Carbon Filter Package
Whole House Chloramine Reduction Filter
WH Chloramine

Chloramine Reduction Filter Package
WHC+ 0.5 Micron Carbon Block Filter
WHC+

0.5 Micron Whole House Carbon Block Filter Package
Whole House KDF / GAC Filter
WH KDF

Combination Whole House KDF / GAC Filter Package
Carbon Type Radial Flow Carbon Block Radial Flow Carbon Block Upflow Granular
(GAC)
Upflow Granular
(GAC)
Radial Flow Catalytic GAC Radial Flow Carbon Block Upflow GAC w/ KDF55
Sediment / Particluate
Chlorine
Chloramine -
Bad Tastes & Odors
Volatile Organic Compounds
Heavy Metals - - - - - - to
Cysts* - - - - - -
Micron Rating 5 microns nominal 5 microns nominal 10 microns nominal 10 microns nominal 10 microns nominal 0.5 microns nominal 5 microns nominal
Max. Recommended Flow Rate (Gallons per Minute)*** 4 GPM
(15 LPM)
6 GPM
(23 LPM)
4 GPM
(15 LPM)
6 GPM
(23 LPM)
5 GPM
(19 LPM)
4 GPM
(15 LPM)
6 GPM
(23 LPM)
Est. Pressure Drop @ Maximum Flow Rate <3.5 PSI <4 PSI <6 PSI <6 PSI <3 PSI <9 PSI <7 PSI
Housings 10" Heavy Duty Big Blue 20" Heavy Duty Big Blue 10" Heavy Duty Big Blue 20" Heavy Duty Big Blue 20" Heavy Duty Big Blue 20" Heavy Duty Big Blue 10" Heavy Duty Big Blue
Sediment Pre-Filter Liquatec
SDF-45-1010

incl. 3 filters
(2 spares)!
Liquatec
SDF-45-2010

incl. 3 filters
(2 spares)!
Liquatec
SDF-45-1010

incl. 3 filters
(2 spares)!
Liquatec
SDF-45-2010

incl. 3 filters
(2 spares)!
Liquatec
SDF-45-2010

incl. 1 filter
Pentek
DGD-5005-20

incl. 1 filter
Liquatec
SDF-45-1010

incl. 3 filters
(2 spares)!
Carbon Filter Pentek
EP-BB

incl. 3 filters
(2 spares)!
Pentek
EP-20BB

incl. 3 filters
(2 spares)!
Pentek
GAC-BB

incl. 3 filters
(2 spares)!
Pentek
GAC-20BB

incl. 3 filters
(2 spares)!
Pentek
CRFC-20BB

incl. 1 filter
Pentek
CBC-20BB

incl. 1 filter
Pentek
DBC-10EX2

incl. 3 filters
(2 spares)!
Est. Filter Life** 22,000 gallons
(83,300 L)
40,000 gallons
(151,400 L)
12,400 gallons
(47,000 L)
30,000 gallons
(113,300 L)
up to 25,000 gallons
(94,600 L)
150,000 gallons
(567,800 L)
20,000 gallons
(75,700 L)
Mounting Bracket Included - Powder-Coated Steel Included - Powder-Coated Steel Included - Powder-Coated Steel Included - Powder-Coated Steel Included - Powder-Coated Steel Included - Powder-Coated Steel Included - Powder-Coated Steel
Spanner Wrench Included Included Included Included Included Included Included
Recommended Operating Temp. Range 40-100F
(4.4 to 37C)
40-100F
(4.4 to 37C)
40-100F
(4.4 to 37C)
40-100F
(4.4 to 37C)
40-100F
(4.4 to 37C)
40-85F
(4.4 to 29C)
40-100F
(4.4 to 37C)
Maximum Recommended Water Pressure 100 PSI
(6.9 bar)
90 PSI
(6.2 bar)
100 PSI
(6.9 bar)
90 PSI
(6.2 bar)
90 PSI
(6.2 bar)
90 PSI
(6.2 bar)
100 PSI
(6.9 bar)
Package Price USA US $279.95
BUY NOW

US $429.95
BUY NOW

US $279.95
BUY NOW

US $429.95
BUY NOW

US $399.95
BUY NOW

US $329.95
BUY NOW

US $359.95
BUY NOW

Package Price Canada CDN $279.95
BUY NOW

CDN $429.95
BUY NOW

CDN $279.95
BUY NOW

CDN $429.95
BUY NOW

CDN $399.95
BUY NOW

CDN $329.95
BUY NOW

CDN $359.95
BUY NOW


*Cryptosporidium and giardia

** Many factors can affect filter life including contaminant levels, flow rates, etc. Please see the Owners' Manual for each model for further details. Most filter life estimates are based on minimum 90% chlorine (chloramine for WH Chloramine model) reduction.

***Most systems can physically handle higher flow rates than recommended, however, contaminant reduction rates will decline at higher flow rates.
