Harmsco SB Swing Bolt Housings
SB housings are versatile, technologically advanced units that give a number of solutions for industrial and municipal applications. With four different sizes, utilizing one, three, five, or eight Hurricane cartridges, this line can handle 150 to 1200 GPM (for most cartridge types). Harmsco's revolutionary Hurricane technology promotes a rotational flow for more equal distribution of contaminants across filter media, combining cartridge filtration with cyclone separation. The NSF-61 certified SB series are designed to meet ASME standards and allow one to choose between 304 or 316 stainless steel for all models.
A chosen housing for municipal drinking water, industrial waste water treatment, and ground water remediation (among many other applications), this electropolished line also features a swing bolt closure system and Harmsco's patented upflow design.
- durable stainless steel construction
- used in industrial and municipal settings
- max flow rates from 150 GPM to 1200 GPM for most cartridge types
- available in either 304 or 316 stainless steel
- housings can function to a maximum of 250 F (121 C)
- rated to a maximum pressure of 150 psi
- NSF-61 validation
|Model||Height||Width||Inlet/Outlet||Flow Rate||Cartridges||Lowest Price
|64"||30"||3" Flange||Up to 450 GPM (1703 LPM)||Three 7-3/4" x 30-3/4"|
|74"||37-1/2"||4" Flange||Up to 750 GPM (2839 LPM)||Five 7-3/4" x 30-3/4"|
|84"||44-1/4"||6" Flange||Up to 1200 GPM (4542 LPM)||Eight 7-3/4" x 30-3/4"|
